Hirschmann RPI-A1-4PoE Injector

Hirschmann RPI-A1-4PoE Injector

Varunummer: 942 226-001

Product description

DescriptionIndustrial, fanless Fast/Gigabit PoE Injector, PoE/PoE+ (IEEE 802.3at), 30W (25.5W at load) per port
Port type and quantity4 x 10/100/1000 BASE-TX ports
TypeRPI-P1-4PoE
Order No.942 226-001

Power requirements

Operating voltage110 - 150 VDC and 100 - 240 VAC
Power consumption160 W

Ambient conditions

Operating temperature-25° to +70°C
Relative humidity (non-condensing)5 % ... 95 %
MTBF137 years (48V/2,7A) (according SN29500, IEC61709)

Mechanical construction

Dimensions (W x H x D)64 mm x 128 mm x 117 m
Weight780 g
Protection classIP20

Approvals

Safety of industrial control equipmentEN60950-1, EN 61131-2 , cUL60950-1 (pending)
TransportationEN50121-4
