KEY FEATURES

Five year warranty

Housing based on 30 years of experience

Lightweight and easy to install

Extremely low wind factor

Integrated design with build-in photocell

and monitoring – no additional power

supply enclosure required

Optimised housing design minimizing the

risk of coating damage during handling and

installation

No maintenance required over service life.

Orga optical design produces highly

accurate and uniform narrow light beam

Integrated GPS based flash synchronization

between lights, UTC 0.0.0.

Extremely low power consumption

Constant power draw – eliminates high

peak power demands especially important

when running from UPS

15 year field proven power supply

technology

Long life power supply to match LED life,

does not use electrolytic capacitors

Made in the Netherlands

PERFORMANCE CHARACTERISTICS

Horizontal beam pattern: 360°

Vertical beam pattern: 3° minimum

Intensity White/Red light: See table

Infra-Red wavelength ~850nm

Infra-Red beam follows visible light, or

beam is according to local standards

STANDARDS/ CERTIFICATION

In compliance with CE

Certified to ICAO Annex 14 Volume 1, Ninth

Edition, July 2022, Chapter 6, Medium

Intensity Type A/ B / C obstacle light

Certified to French “Arrêté du 23 avril 2018

relatif à la réalisation du balisage des

obstacles à la navigation aérienne”

Certified to United States Federal Aviation

Administration AC150/5345-43J, March 2019

including Engineering brief 67D

Certified to AVV (German “General

Administrative Regulation for the marking

and lighting of obstacles to air navigation”)

“Feuer W, rot”

Certified to specific requirements for

obstruction lights described in UK CAA CAP

393 article 220 (10 January 2015) and Policy

Statement of November 2012 concerning

lighting and marking of wind turbines in UK

territorial waters

Complies with The UK Air Navigation Order

2016, section 222

Complies with CAP764 Policy and

Guidelines on Wind Turbines Iss 6 Feb 2016

Complies with UK MOD Requirements for

Infrared light for windturbines

Complies with Swiss AD I-006 D

richtlinie_luftfahrthindernisse

Complies with Lithuanian Standard,

Marking of Obstacles 20200326Various

national approvals available upon request

PHYSICAL CHARACTERISTICS

Dimensions: L x W x H: See drawing

Weight: 12kg

Design degree of protection: IP65

Operating temperature range: -40 ºC/+55 ºC

Shipping information: 550 x 550 x 400 mm;

approx. 16 kg

Supplied with pre-mounted Orga cable for

easy installation and high reliability ready

for use

Cable bending radius static: 10x cable

diameter

Outer cable diameter: Ø12.5 +/- 0.5 mm

Cable weight: 260 g/m

Level indicators for correct mounting

SYSTEM DESIGN, CONTROL AND

MONITORING

Use as a stand-alone light, or in a multiple

light system with an Orga CIP controller

Optional Orga CIP controller facilities

provides control interfaces for:

“smart switch” aircraft detection input

Visibility condition variable intensity input

Visibility condition variable intensity input;

intensity steps 30% and 10%

Remote photocell control input/override

ELECTRICAL CHARACTERISTICS

Available Operating voltages: 120-240Vac

nominal 50-60Hz, see table

Power consumption: See table, IR: ±1W

Overvoltage protection: Class III according

to IEC61643-1
