Orga Helideck Perimeter Light L85EX-G-DC 30cd, 24V DC, IP66, 2XM25

Orga Helideck Perimeter Light L85EX-G-DC

30cd, 24V DC, IP66, 2XM25

Varenr: 071942



KEY FEATURES

  • Reliable (recessed) mounted helideck perimeter light
  • Low cost of ownership
  • Low power consumption
  • Serviceable unit, parts are interchangeable
  • Certified for Zone 1 and 2 areas with increased gas explosion hazard
  • Compact design, meeting the maximum 50 mm height restrictions of IMO
  • Intensity main beam 30cd green (CAP437)
  • Impact resistant dome and stainless steel 316 body
  • Spacious, cable connection compartment
  • Photometric test of independent institution

STANDARDS/CERTIFICATION

  • Certified to CAA-UK CAP 437; Offshore helicopter landing areas – Guidance on standards, 7th edition, chapter 4, paragraph 3.1
  • Certified to IMO standard MODU code; 2009 (Edition 2010), chapter 13.5.21
  • Certified to ICAO Annex 14, Volume ll; International standards and recommended practices: Aerodromes, 3rd edition, July 2009, chapter 5.3.8
  • Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
  • SIRA 12ATEX3066; ATEX Ex II 2G Ex e mb IIC T4 Gb
  • IEC 60079-0, IEC 60079-7 and IEC 60079-18
  • IECEx SIR 12.0026; Ex e mb IIC T4 Gb
  • ABNT NBR IEC 60079-0, ABNT NBR IEC 60079-7 and ABNT NBR IEC 60079-18
  • NCC 12.1223; Ex e mb IIC T4 Gb (optional)

PERFORMANCE CHARACTERISTICS

  • Steady burning; green
  • Intensity: 30cd (60cd maximum)
  • Horizontal beam coverage: 360°
  • Vertical beam profile: as per CAP437 table
  • Colour chromaticity within the boundaries as specified by ICAO
  • Light source: LED

ELECTRICAL CHARACTERISTICS

  • Operating voltage: see table
  • Power consumption: see table
  • Connection details: M4; two M25x1.5 cable entries
  • Earth connection: internal M4 and external M6

PHYSICAL CHARACTERISTICS

  • Dimensions (Ø x H):
    see drawing
  • Weight: see table
  • Design degree of protection: IP66
  • Operating temperature range:
    -40°C to +60°C
